СОАС-10-3
<table width="660px" cellspacing="1" cellpadding="5" border="1" align="center">
<thead>
<tr>
<td rowspan="2" align="center">
Марка зажима
</td>
<td rowspan="2" align="center">
Рис.
</td>
<td colspan="3" align="center">
Размеры, мм
</td>
<td rowspan="2" align="center">
Масса, кг
</td>
<td colspan="2" align="center">
Для проводов
</td>
<td colspan="5" align="center">
Прочность заделки Р, кН, проводов марок, не менее
</td>
</tr>
<tr>
<td align="center">
b<sub>1</sub>
</td>
<td align="center">
b<sub>1</sub>
</td>
<td align="center">
L
</td>
<td align="center">
по ГОСТ 839-80
</td>
<td align="center">
Марки АЖС по ТУ 16-705.183-81
</td>
<td align="center">
А, АКП
</td>
<td align="center">
АН, АНКП
</td>
<td align="center">
АЖ, АЖКП
</td>
<td align="center">
АС, АСК, АСКП, АСКС
</td>
<td align="center">
АЖС
</td>
</tr>
</thead>
<tbody>
<tr>
<td align="center">
СОАС-10-3
</td>
<td rowspan="9" align="center">
1
</td>
<td align="center">
5,0
</td>
<td align="center">
10,6
</td>
<td align="center">
200
</td>
<td align="center">
0,026
</td>
<td align="center">
10/1,8
</td>
<td align="center">
-
</td>
<td align="center">
-
</td>
<td align="center">
-
</td>
<td align="center">
-
</td>
<td align="center">
3,680
</td>
<td align="center">
-
</td>
</tr>
<tr>
<td align="center">
СОАС-16-3
</td>
<td align="center">
6,25
</td>
<td align="center">
12,5
</td>
<td align="center">
250
</td>
<td align="center">
0,045
</td>
<td align="center">
16; 16/2,7
</td>
<td align="center">
-
</td>
<td align="center">
2,719
</td>
<td align="center">
3,195
</td>
<td align="center">
4,192
</td>
<td align="center">
5,598
</td>
<td align="center">
-
</td>
</tr>
<tr>
<td align="center">
СОАС-25-3
</td>
<td align="center">
7,5
</td>
<td align="center">
15,2
</td>
<td align="center">
</td>
<td align="center">
0,050
</td>
<td align="center">
25; 25/4,2
</td>
<td align="center">
-
</td>
<td align="center">
4,050
</td>
<td align="center">
4,595
</td>
<td align="center">
6,275
</td>
<td align="center">
8,366
</td>
<td align="center">
-
</td>
</tr>
<tr>
<td align="center">
СОАС-35-3
</td>
<td align="center">
9,2
</td>
<td align="center">
19,0
</td>
<td align="center">
330
</td>
<td align="center">
0,130
</td>
<td align="center">
35; 35/6,2
</td>
<td align="center">
-
</td>
<td align="center">
5,322
</td>
<td align="center">
6,328
</td>
<td align="center">
8,640
</td>
<td align="center">
12,172
</td>
<td align="center">
-
</td>
</tr>
<tr>
<td align="center">
СОАС-50-3
</td>
<td align="center">
10,5
</td>
<td align="center">
22,0
</td>
<td align="center">
400
</td>
<td align="center">
0,160
</td>
<td align="center">
50; 50/8,0
</td>
<td align="center">
-
</td>
<td align="center">
7,378
</td>
<td align="center">
9,126
</td>
<td align="center">
12,444
</td>
<td align="center">
15,401
</td>
<td align="center">
-
</td>
</tr>
<tr>
<td align="center">
СОАС-70-3
</td>
<td align="center">
12,5
</td>
<td align="center">
26,0
</td>
<td align="center">
450
</td>
<td align="center">
0,230
</td>
<td align="center">
70; 70/11
</td>
<td align="center">
-
</td>
<td align="center">
10,159
</td>
<td align="center">
-
</td>
<td align="center">
-
</td>
<td align="center">
21,717
</td>
<td align="center">
-
</td>
</tr>
<tr>
<td align="center">
СОАС-95-3
</td>
<td align="center">
15,0
</td>
<td align="center">
31,0
</td>
<td align="center">
750
</td>
<td align="center">
0,456
</td>
<td align="center">
95; 120; 95/16
</td>
<td align="center">
70/39
</td>
<td align="center">
13,306; 17,901
</td>
<td align="center">
21,570
</td>
<td align="center">
29,416
</td>
<td align="center">
30,032
</td>
<td align="center">
58,5
</td>
</tr>
<tr>
<td align="center">
СОАС-120-3
</td>
<td align="center">
17,0
</td>
<td align="center">
35,0
</td>
<td align="center">
900
</td>
<td align="center">
0,760
</td>
<td align="center">
150; 120/19; 120/27
</td>
<td align="center">
-
</td>
<td align="center">
21,978
</td>
<td align="center">
27,298
</td>
<td align="center">
37,227
</td>
<td align="center">
37,369 44,518
</td>
<td align="center">
-
</td>
</tr>
<tr>
<td align="center">
СОАС-150-3
</td>
<td align="center">
19,0
</td>
<td align="center">
39,0
</td>
<td align="center">
1000
</td>
<td align="center">
0,920
</td>
<td align="center">
150/19; 150/24; 150/34
</td>
<td align="center">
-
</td>
<td align="center">
-
</td>
<td align="center">
-
</td>
<td align="center">
-
</td>
<td align="center">
41,676; 47,051; 56,379
</td>
<td align="center">
-
</td>
</tr>
<tr>
<td align="center">
СОАС-185-3
</td>
<td align="center">
2
</td>
<td align="center">
43
</td>
<td align="center">
21
</td>
<td align="center">
1050
</td>
<td align="center">
1,210
</td>
<td align="center">
185; 185/24; 185/29; 185/43
</td>
<td align="center">
</td>
<td align="center">
26,849
</td>
<td align="center">
33,705
</td>
<td align="center">
45,956
</td>
<td align="center">
52,268; 55,850; 69,990
</td>
<td align="center">
-
</td>
</tr>
</tbody>
</table>
